| hose cover material | synthetic rubber | ||
| Maximale Betriebstemperatur | 257 °f (water: 185, air: 158), 125 °c (water: 85, air: 70) | ||
| specifications met | parker specifications | ||
| Gewicht | 0.28 lb/ft, 0.42 kg/m | ||
| industry | industrial manufacturing equipment, off-road machinery, transportation | ||
| hose inner tube material | nitrile nbr | ||
| Minimale Betriebstemperatur | -40 °c, -40 °f | ||
| Produktfamilie | specialty hose | ||
| materials of construction | rubber | ||
| division | polymer hose division europe | ||
| minimum bend radius | 2.559 inch, 65 mm | ||
| hose inside diameter | 3/8 inch, 9.5 mm | ||
| Anwendung | industrial & mobile applications-power steering circuits |
| hose i.d. (size) | -6 | ||
| hose reinforcement material | 2 high tensile steel wire braids | ||
| cover material | synthetic rubber | ||
| hose outside diameter | 0.677 inch, 17.2 mm | ||
| cover color | black | ||
| Brand | parker | ||
| maximum operating pressure | 280 bar, 28 mpa, 4000 psi | ||
| technology | fluid & gas handling | ||
| design factor | 4:1 | ||
| product style | no-skive compact | ||
| media | petroleum, water-glycol fluids, lubricating oils, air & water, fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, industrial air, lubricants, water | ||
| compatible fitting | 48 series |
