| Under roller diameter | Fw | 6 | mm |
| Width, outer ring | B | 15 | mm |
| Limiting load | (Fr*n)max | 18,000 | |
| Limiting speed for rotating outer ring | nGA | 13,000 |
| Außen-Ø | D | 10 | mm |
| Minimum chamfer dimension | rmin | 0,30 | mm |
| Zulässige Radiallast | Fr max | 110 | N |
| Limiting speed for rotating shaft | nGW | 23,000 |
| Permissible torque | Md per | 0,37 | Nm |
