| pumps | pvws-250 | ||
| Typ | w : w (3) w type | ||
| separator | - (5) separator | ||
| basic standard | m : m (9) metric | ||
| rotation direction | r : r (12) right hand rotation | ||
| thru-drive options | 00 : 00 (14,15) no through drive | ||
| main port orientation | r : r (17) a & b ports radial | ||
| drive shaft seal configuration | s : s (20) single shaft seal | ||
| yoke position indicator | v : v (22) optical position indicator | ||
| control type | df : df (24,25) pressure compensator | ||
| electronic control (only for sp control) | 00 : 00 (27,28) without electronics | ||
| extra functions | 0 : 0 (30) no extra function | ||
| control options | 000 : 000 (32-34) no power control | ||
| venting valve | 0 : 0 (36) no unloading valve | ||
| electric motor type (es only) | 0 : 0 (38) no electric motor | ||
| cust adjustment spec | 0000 : 0000(40-43) no customer adjustment spec. | ||
| design number | 10 : 10 (47,48) design number |
| Baureihe | pv : pv (1,2) variable pump | ||
| configuration | s : s (4) single unit | ||
| Schluckvolumen | 250 : 250 (6,7,8) displ 250cc | ||
| Befestigungsflansch | 07 : 07 (10,11) iso 200 4 hole flange 250,360cc | ||
| adjustment stops | 0 : 0 (13) no adjustment stops | ||
| main ports | 1 : 1 (16) a & b ports sae, metric thread | ||
| main drive shaft end | 01 : 01 (18,19) keyed shaft iso | ||
| seal material | v : v (21) fkm seals | ||
| paint | a : a (23) painted blue | ||
| displacement adj option | 0 : 0 (26) not applicable | ||
| yoke displacement zone | a : a (29) single side of center | ||
| pressure control options | 0 : 0 (31) standard | ||
| pilot oil filter | 0 : 0 (35) no pilot oil filter | ||
| position monitoring | 0 : 0 (37) no position monitoring | ||
| voltage of valve | 0 : 0 (39) control voltage not applicable | ||
| special features | 000 : special features |
