| Shoulder diameter inner ring | d1 | 40 | mm |
| Minimum chamfer dimension | rmin | 1 | mm |
| Shoulder diameter outer ring | D1 | 52,10 | mm |
| Maximum fillet radius | ra max | 1 | mm |
| Minimum diameter shaft shoulder | da min | 35,60 | mm |
| Maximum diameter of housing shoulder | Da max | 56,40 | mm |
| Limiting speed | nG | 16,500 | |
| Basic static load rating, radial | C0r | 12,900 | |
| Breite | B | 16 | mm |
| Bore diameter | d | 30 | mm |
| Fatigue load limit, radial | Cur | 510 | N |
| Basic dynamic load rating, radial | Cr | 23,000 | |
| Außen-Ø | D | 62 | mm |
