| Angle between Set Screws | 90 º | ||
| Set Screw Size | M8 x 1.25 | ||
| Abmessung J | 8 | ||
| Dimension S1 | 30,17 | mm | |
| Radius r | 0,60 | mm | |
| Inner Ring Width B | 49,22 | mm |
| Number of Set Screws | 2 | ||
| Abmessung M | 4,55 | mm | |
| Abmessung F | 52,27 | mm | |
| Center of Bearing from End S | 19,05 | mm | |
| Outside Ring Width C | 22 | mm | |
| Outside Diameter D | 85 | mm |
| Gewicht | 0,20 | Kg | |
| Sub Series | GYM..KRRB | ||
| O.D. Type | Spherical OD | ||
| Material | Bearing Steel | ||
| Bore Type | Cylindrical bore |
| Seal Type | Shroud Seal | ||
| Baureihe | Medium-Duty | ||
| Schmierausführung | Relubricatable | ||
| Bearing Type | Ball Bearing | ||
| Shaft Size d | 1 1/2 in |
