| Bore diameter bearing | d | 16 | mm |
| Width inner ring | B | 21 | mm |
| Basic static load rating, radial | C0r | 53,600 |
| Outside diameter bearing | D | 32 | mm |
| Basic dynamic load rating, radial | Cr | 21,400 |
| Connection measure Inner ring | da max | 19,30 | mm |
| Width Outer ring | C | 15 | mm |
| Tilt angle | α | 15 | ° |
| Bore diameter bearing, upper tolerance | dOT | 0,02 | mm |
| Outside diameter, lower tolerance | Do UT | -0,01 | mm |
| Width inner ring, lower tolerance | BUT | -0,12 | mm |
| Ball diameter | dK | 28,58 | mm |
| Edge Spacing | r1smin | 0,30 | mm |
| Bore diameter bearing, tolerance | dT | H7 | |
| Radialluft | Gr | 0,006 - 0,035 |
