| Bore diameter bearing | d | 45 | mm |
| Width inner ring | B | 32 | mm |
| Basic static load rating, radial | C0r | 259,000 |
| Outside diameter bearing | D | 68 | mm |
| Basic dynamic load rating, radial | Cr | 128,000 |
| Edge Spacing | r1smin | 0,60 | mm |
| Ball diameter | dK | 60 | mm |
| Outer eye diameter | d2 | 102 | mm |
| Shank Length External thread rod | h | 163 | mm |
| Tilt angle | α | 7 | ° |
| Total length external thread head | l2 | 214 | mm |
| Radialluft | Gr | 0,043 - 0,12 | |
| Width inner ring, lower tolerance | BUT | -0,12 | mm |
| Outer flange diameter inner ring | d1 | 50,70 | mm |
| Thread size | d3 | M42x3 | |
| Width of the rod end | C1 | 27 | mm |
| Shank Length External thread head | l1 | 94 | mm |
| Distance drilling with/shaft start | l7 | 52 | mm |
| Bore diameter bearing, lower tolerance | dUT | -0,01 | mm |
| Hersteller | Teilenummer |
|---|---|
| SKF | SALA45 ES-2RS (SKF) |
