| hydraulic hose | hose, sktls/r6 | ||
| dash size | 8 | ||
| max temperature (c) | 150 | ||
| min temperature (c) | -40 | ||
| operating pressure (psi) | 250 | ||
| product line | aeroquip | ||
| agency listings: industry specification | abs | ||
| burst pressure (psi) | 1.000 | ||
| family | hose | ||
| hose base number | fc332 | ||
| Inside Diameter (mm) | 12,70 | ||
| min bend radius (mm) | 127 | ||
| Outside Diameter (mm) | 19,10 | ||
| vacuum (inhg) | 28 | ||
| weight (kg/m) | 0,22 |
| cover material | aqp | ||
| hose family | socketless/r6 | ||
| max temperature (f) | 302 | ||
| min temperature (f) | -40 | ||
| operating pressure (bar) | 17 | ||
| tube material | aqp | ||
| burst pressure (bar) | 70 | ||
| description | low pressure socketless textile braid | ||
| general application | for gasoline, fuel and lubricating oils, air and water | ||
| Inside Diameter (in) | 0,50 | ||
| min bend radius (in) | 5 | ||
| Outside Diameter (in) | 0,75 | ||
| reinforcement material | textile braid reinforcement | ||
| vacuum (kpa) | 94,80 | ||
| weight (lb/ft) | 0,15 |
