| body | aluminium | ||
| bowl type | metal with liquid level indicator | ||
| elastomers | neoprene | ||
| filter element m particlesize micron | 40 μm | ||
| flow flow dm3secbar | 83 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 175 °f | ||
| partially replaced part | f84g-4gn-qd3 | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
| bowl | diecast aluminium | ||
| Ablauftyp | manual | ||
| filter element | sintered polypropylene | ||
| flow flow dm3sec | 66 dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 250 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 80 °c | ||
| Anschlussgröße | g1/2 | ||
| range | f74g | ||
| retrieve price | true | ||
| service life indicator | with |
