| body | aluminium | ||
| bowl type | metal | ||
| elastomers | neoprene | ||
| flow flow dm3sec | 16 dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 247 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 65 °c | ||
| particle removal particlesize micron | 0.01 μm | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
| bowl | diecast aluminium | ||
| Ablauftyp | manual | ||
| filter element m particlesize micron | 0.01 μm | ||
| flow flow dm3secbar | 16 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -29 ... 149 °f | ||
| partially replaced part | f84c-3gd-qd0 | ||
| Anschlussgröße | g3/8 | ||
| range | f74c | ||
| retrieve price | true | ||
| service life indicator | with |
