| body | aluminium | ||
| bowl type | polymer with guard | ||
| elastomers | neoprene | ||
| flow flow dm3sec | 10 dm3/sec | ||
| flow imperial flow scfm | 21.2 scfm | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 122 °f | ||
| partially replaced part | f84c-3ad-ap0 | ||
| Anschlussgröße | 3/8" ptf | ||
| range | f73c | ||
| retrieve price | true | ||
| service life indicator | with |
| bowl | polycarbonate | ||
| Ablauftyp | automatic drain | ||
| filter element m particlesize micron | 0.01 μm | ||
| flow flow dm3secbar | 10 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 150 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 50 °c | ||
| particle removal particlesize micron | 0.01 μm | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
