| body | zinc | ||
| bowl type | metal with liquid level indicator | ||
| data performance shelf life | 3 years | ||
| elastomers | nitrile rubber | ||
| flow flow dm3sec | 4.5 dm3/sec | ||
| flow imperial flow scfm | 9.5 scfm | ||
| maximum inlet pressure pressure bar | 8 bar | ||
| operating temperature f temperature fahrenheit min to max range | -29 ... 149 °f | ||
| partially replaced part | f82c-2gd-ad0 | ||
| Anschlussgröße | g1/4 | ||
| range | f72c | ||
| retrieve price | true | ||
| service life indicator | with |
| bowl | diecast zinc | ||
| cadfilestep | norgren-f72c-2xd-ae0.step | ||
| Ablauftyp | automatic drain | ||
| filter element m particlesize micron | 0.01 μm | ||
| flow flow dm3secbar | 4.5 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 116 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 65 °c | ||
| particle removal particlesize micron | 0.01 μm | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
