FESTO EMMS
596 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO EMMS – Motor. Finden Sie das passende Produkt durch Filtern mit Motor type, Flange size, motors, Length, Output shaft, Winding, Elektrischer Anschluss, Measuring unit, Generation 1st generation, Brake und Degree of protection, electrical system.
EMMS Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| EMMS | EMMS-AS- - - - - | Motor |
| EMMS | EMMS-ST- - -S | Motor |
Typcode zur Katalognummer EMMS,
EMMS-AS- - - - -
| 001 | Series |
|---|---|
| EMMS | Motor |
| 002 | Motor type |
| AS | AC synchronous |
| 003 | Flange size, motors |
| 40 | 40 |
| 55 | 55 |
| 70 | 70 |
| 100 | 100 |
| 140 | 140 |
| 190 | 190 |
| 004 | Length |
| S | Short |
| M | Centre |
| L | Long |
| 005 | Output shaft |
| Smooth shaft | |
| K | Shaft to DIN 6885 |
| 006 | Winding |
| LS | Low voltage, standard |
| LV | Low voltage, speed optimised |
| HS | High voltage, standard |
| HV | High voltage, speed optimised |
| 007 | Electrical connection |
|---|---|
| T | Terminal box |
| A | Angled plug |
| R | Angled connector, adjustable |
| S | Straight plug |
| 008 | Measuring unit |
| R | Resolver |
| S | Absolute encoder, single turn |
| M | Absolute encoder, multi-turn |
| 009 | Brake |
| None | |
| B | With brake |
| 010 | Degree of protection, electrical system |
| Standard | |
| S1 | IP65 |
Typcode zur Katalognummer EMMS,
EMMS-ST- - -S
| 001 | Series |
|---|---|
| EMMS | Motor |
| 002 | Motor type |
| ST | Stepper motor ST |
| 003 | Flange size, motors |
| 28 | 28 |
| 42 | 42 |
| 57 | 57 |
| 87 | 87 |
| 004 | Length |
| S | Short |
| M | Centre |
| L | Long |
| 005 | Electrical connection |
|---|---|
| S | Straight plug |
| 006 | Measuring unit |
| None | |
| E | Encoder |
| 007 | Brake |
| None | |
| B | With brake |
| 008 | Generation 1st generation |
| 1st generation | |
| G2 | 2nd generation |
