| Material yoke plate | Steel | ||
| Material guide component | Tempered steel | ||
| Befestigungsart | Via female thread | ||
| Centre of gravity at 0 mm stroke | 30 mm | ||
| Bewegte Masse | 1.300 g | ||
| Max. torque Mz static | 46 Nm | ||
| Max. torque My static | 46 Nm | ||
| Max. torque Mx static | 38 Nm | ||
| Max. force Fz static | 1.020 N | ||
| Max. force Fy static | 1.020 N | ||
| Umgebungstemperatur | -20 °C ... 80 °C | ||
| Konstruktiver Aufbau | Guidance | ||
| Einbaulage | optional | ||
| Hub | 320 mm |
| Werkstoff Gehäuse | Wrought aluminium alloy Anodised | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| Centre of gravity additional of moving mass per 10 mm | 4,1 mm | ||
| Produktgewicht | 2.261 g | ||
| Displacement force | 15 N | ||
| Max. Moment Mz | 34 Nm | ||
| Max. Moment My | 34 Nm | ||
| Max. Moment Mx | 28 Nm | ||
| Max. Kraft Fz | 750 N | ||
| Max. Kraft Fy | 750 N | ||
| Korrosionsbeständigkeitsklasse KBK | 0 - No corrosion stress | ||
| Führung | Recirculating ball bearing guide | ||
| Reversing backlash theoretical | 0 µm | ||
| Baugröße | 32 |
