FESTO DFPC
16 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO DFPC – Linear drive. Finden Sie das passende Produkt durch Filtern mit Piston diameter [mm] und Stroke [mm].
DFPC Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| DFPC | DFPC- - -D | Linear drive |
Typcode zur Katalognummer DFPC,
DFPC- - -D
| 001 | Series |
|---|---|
| DFPC | Linear drive |
| 002 | Piston diameter [mm] |
| 80 | 80 |
| 100 | 100 |
| 125 | 125 |
| 160 | 160 |
| 200 | 200 |
| 250 | 250 |
| 320 | 320 |
| 003 | Stroke [mm] |
| 50 | 50 |
| 65 | 65 |
| 80 | 80 |
| 100 | 100 |
| 125 | 125 |
| 150 | 150 |
| 200 | 200 |
| 250 | 250 |
| 300 | 300 |
| 350 | 350 |
| 400 | 400 |
| ... | 10 ... 1600 |
| 004 | Function |
| D | Double-acting |
| 005 | Piston rod thread type |
| Male thread | |
| 006 | Housing surface treatment |
| None | |
| 007 | EU certification |
| None | |
| EX4 | II 2GD |
| 008 | Piston rod extension |
|---|---|
| None | |
| ...E | 1 ... 500 mm |
| 009 | Piston rod thread extension |
| None | |
| ...L | 0 ... 70 mm |
| 010 | Piston rod thread shortening |
| None | |
| ...S | 1 ... 74 mm |
| 011 | Piston rod thread |
| Standard | |
| M16 | M16 |
| M16P | M16x1.5 |
| M20 | M20 |
| M20P | M20x1.5 |
| M24 | M24 |
| M24P | M24x2 |
| M27 | M27 |
| M27P | M27x2 |
| M30 | M30 |
| M30P | M30x2 |
| M36 | M36 |
| M36P | M36x2 |
| M42 | M42 |
| M42P | M42x2 |
| M48 | M48 |
| M48P | M48x2 |
| 012 | Thread length of spacer bolts on bearing cap |
| None | |
| ...LB2 | 10 ... 140 mm |
