| body | plastic pbt | ||
| collar | nickel plated brass | ||
| grabring | stainless steel | ||
| od tube length millimetre | 12 mm | ||
| operating pressure psi pressure psi min to max range | 0 ... 145 psi | ||
| operating temperature temperature celsius min to max range | -20 ... 60 °c | ||
| release sleeve and backing ring | pom | ||
| Baureihe | pneufit c | ||
| thread | g1/2 | ||
| thread sealant | threebond 2350b | ||
| threaded bodies | nickel plated brass |
| bspp | g1/2 | ||
| data performance shelf life | 10 years | ||
| Medium | compressed air | ||
| operating pressure pressure bar min to max range | 0 ... 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 140 °f | ||
| Anschlussgröße | g1/2 | ||
| Dichtungen | nbr (silicone free) | ||
| shape | straight | ||
| thread form | iso g | ||
| Thread Type | iso rc |
