| Minimum chamfer dimension | rmin | 1,50 | mm |
| Contact angle | α | 60 | ° |
| Distance between the apexes of the pressure cones | a | 75 | mm |
| Bore diameter | d | 45 | mm |
| Außen-Ø | D | 100 | mm |
| Breite | B | 20 | mm |
| Basic dynamic load rating, axial | Ca | 62,000 | |
| Fatigue load limit, axial | Cua | 7,800 | |
| Thermally safe operating speed | nϑ | 2,700 |
| Bore diameter lower tolerance | -0,01 | mm | |
| Outside diameter lower tolerance | -0,01 | mm | |
| Width lower tolerance | -0,12 | mm | |
| Basic static load rating, axial | C0a | 172,000 | |
| Limiting speed for grease lubrication | nG Grease | 4,000 |
| Diameter of housing | Da | 85,50 | mm |
| Diameter shaft | da | 64,50 | mm |
| Diameter of housing clearance | Da | H12 | |
| Diameter shaft clearance | da | h12 |
