| Bezeichnung | BNU02510RSULL4B-B0 | ||
| Baureihe | BNU | ||
| Pitch P | 10 mm | ||
| Mutternart | SU - Single nut with flange (DIN 69051) | ||
| Dw | 4,762 mm | ||
| D2 | 62 mm | ||
| D3 | 51 mm | ||
| X | 6,6 mm | ||
| Number of circuits | 1 x 4 | ||
| DN value for P5 | 80000 mmpm | ||
| C0a for T7 | 57,951 kN | ||
| C0a for P5 | 64,39 kN |
| Brand | SNR | ||
| d0 | 25 mm | ||
| Pitch direction | Right | ||
| Material | Carbon steel | ||
| D1 g6 | 40 mm | ||
| L - Length | 85 mm | ||
| H | 48 mm | ||
| Q | 0 mm | ||
| DN value for T7 | 70000 mmpm | ||
| Ca for T7 | 23,472 kN | ||
| Ca for P5 | 26,08 kN | ||
| Kn | 490 N/µm |
