| Bore diameter | d | 85 | mm |
| Höhe | T | 6 | mm |
| Contact-angle | α | 60 | ° |
| Outer diameter | Do | 99 | mm |
| Tolerance height min. | -0,50 | mm | |
| Basic dynamic load rating, axial | Ca | 109,000 |
| Centering on the shaft | da | 85 | mm |
| Centering tolerance in the housing min. | -0,20 | mm |
| Centering tolerance in the housing max. | -0,10 | mm |
