| Baureihe | afd40 | ||
| fluid | air | ||
| maximum operating pressure | 1.0 mpa | ||
| ambient and fluid temperature | ?5 to 60c (with no freezing) | ||
| nominal filtration rating | 0.01 ?m (95% filtered particle size) | ||
| bowl material | polycarbonate | ||
| drain capacity (cm3) | 45 | ||
| Gewicht | 1.19049 lb |
| Anschlussgröße | 1/43/81/2 | ||
| proof pressure | 1.5 mpa | ||
| minimum operating pressure | 0.05 mpa | ||
| rated flow ( /min (anr)) (1) | 600 | ||
| outlet side oil mist concentration | max. 0.1 mg/m3 (anr) (before saturated with oil: 0.01 mg/m3 (anr) or less, approx. 0.008 ppm) (2) | ||
| Bowl guard | standard | ||
| weight (kg) | 0,44 |
