| Gewicht | 1.81973 lb | ||
| regulator construction | relieving type | ||
| bowl material | polycarbonate | ||
| relief pressure | set pressure + 0.05 mpa note 3) [at relief flow rate of 0.1 l/min (anr)] | ||
| maximum operating pressure | 1.0 mpa | ||
| ambient and fluid temperature note 2) | ?5 to 60c (with no freezing) | ||
| pressure gauge port size note 1) | 1/8 | ||
| component - regulator | ar30 | ||
| Baureihe | ac30b |
| mass (kg) | 0,63 | ||
| Bowl guard | standard | ||
| nominal filtration rating | 5 ?m | ||
| set pressure range | 0.05 to 0.85 mpa | ||
| proof pressure | 1.5 mpa | ||
| fluid | air | ||
| Anschlussgröße | 1/4, 3/8 | ||
| component - air filter | af30 |
