| ras max - Max shaft & housing fillet radius | 2,1 mm | ||
| da min - Min shoulder diameter IR | 175 mm | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Oil lubrication limit speed | 1800 tr/min | ||
| C0a - Static axial load rating | 1890 kN | ||
| Eb - Rollers reference inner diameter | 94 mm | ||
| Bearing ring (outer ring) GS | GS87417 | ||
| Cage assembly reference | K87417 | ||
| D - Outside diameter of support washer OR - GS | 180 mm |
| Db max - Max OR shoulder diameter | 93 mm | ||
| BSF - Characteristic rolling element frequency | 10,308 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Nlim - Grease lubrication limit speed | 450 tr/min | ||
| Ca - Dynamic axial load rating | 430 kN | ||
| Ea - Rollers reference outer diameter | 174 mm | ||
| Bearing ring (inner ring) WS | WS87417 | ||
| rs - Min fillet radius | 2,1 mm | ||
| Brand | NTN |
