| Werkstoff-Hinweis | RoHS-compliant | ||
| Types of communication | IO-Link® | ||
| IO-Link, minimale Zykluszeit | Device 3.2 ms | ||
| IO-Link, Number of ports | Device 1 | ||
| IO-Link, Communication mode | COM2 (38.4 kBaud) | ||
| IO-Link, connection technology | Device, 5-pin | ||
| LABS-Konformität | VDMA24364-B2-L | ||
| Restwelligkeit | 4 Vpp | ||
| Intrinsic current consumption at nominal operating voltage load | Typ. 30 mA | ||
| Baud rate | 38.4 kbps | ||
| Max. number of valve positions | 16 |
| Leiter-Nennquerschnitt | 1 mm² | ||
| Max. Leitungslänge | 20 m | ||
| IO-Link, Prozessdatenbreite OUT | Device 1-4 Byte | ||
| IO-Link, Port class | Device B | ||
| IO-Link, Protokollversion | Device V 1.1 | ||
| Produktgewicht | 690 g | ||
| Korrosionsbeständigkeitsklasse KBK | 2 - Moderate corrosion stress | ||
| Nennbetriebsspannung DC | 24 V | ||
| Intrinsic current consumption at nominal operating voltage for electronics/sensors | Typically 30 mA | ||
| Max. number of valve coils | 32 | ||
| Verpolungsschutz | Separate for power system (PS) and power load (PL) |
