| Color | red | ||
| hose reinforcement material | high tensile fibre braid | ||
| hose outside diameter | 0.764 inch, 19.4 mm | ||
| cover color | red | ||
| Brand | parker | ||
| Produktfamilie | push-lok and push-on hoses | ||
| materials of construction | rubber | ||
| vacuum pressure rating | 0.95 bar, 28.05 inch-hg, 712.56 mm-hg | ||
| product style | push-lok plus | ||
| Gewicht | 0.18 lb/ft, 0.27 kg/m | ||
| hose inside diameter | 1/2 inch, 12.7 mm | ||
| Maximale Betriebstemperatur | 212 °f (water: 185, air: 158), 100 °c (water: 85 , air: 70) | ||
| cover material | high performance synthetic rubber in different colours |
| hose i.d. (size) | -8 | ||
| specifications met | parker specifications | ||
| industry | general industrial, marine, transportation | ||
| hose inner tube material | nitrile nbr | ||
| maximum operating pressure | 21 bar, 2.1 mpa, 300 psi | ||
| technology | fluid & gas handling | ||
| design factor | 4:1 | ||
| division | polymer hose division europe | ||
| minimum bend radius | 4.921 inch, 125 mm | ||
| media | air, water-glycol-emulsions, mineral based hydraulic, lubricating oils, coolants i.e. water-glycol, industrial air, lubricants, mineral hydraulic oil, water | ||
| compatible fitting | 82 series | ||
| Minimale Betriebstemperatur | -40 °c | ||
| Anwendung | all markets: for low pressure applications paper and pulp: for water/air applications |
