| motors | hhd763027bc00000000000a | ||
| Schluckvolumen | 76 : 124,80 cm3/r [7.616 in3/r] at 18 deg. swashplate angle | ||
| Design type | 0 : ball-guide - (model 76) | ||
| main ports | b : [1.00] sae 4-bolt split flange port, high pressure series (code 62) | ||
| charge pressure relief valve | 0 : no relief valve | ||
| high pressure relief valve - port a | 0 : none | ||
| high pressure relief valve - port b | 0 : none | ||
| speed sensor | 0 : no speed sensor | ||
| paint and packaging | 0 : painted primer blue | ||
| design code | a : a |
| Product identification | hhd : heavy duty hydrostatic fixed displacement motor | ||
| Typ | 3 : fixed displacement motor | ||
| output shaft | 27 : 27 tooth 16/32 pitch spline (model 76) | ||
| end cover and composite valve block assy | c : no composite valve block - with cover plate | ||
| charge pressure relief valve setting | 0 : standard | ||
| high pressure rel valve setting - port a | 0 : none | ||
| high pressure rel valve setting - port b | 0 : none | ||
| special features | 00 : no special features | ||
| identification on unit | 0 : standard |
