| pumps | vmq23525s125080b00500bbb ccanr00a032 | ||
| frame size (front section) | 35 : 90-140 cm3/r [5.49-8.54 in3/r] | ||
| pump type | s : standard double pump | ||
| displacement (rear section) | 080 : 80.0 cm3/r [4.88 in3/r] 25 frame size | ||
| adapter mount/orient. (cover end view) | 0 : none (standard double pump) | ||
| output shaft coupling | 00 : none (standard double pump) | ||
| front outlet port type | b : 4-bolt flange per sae j518 with metric threads | ||
| front outlet port pos. (cover end view) | c : front outlet port in-line with inlet port | ||
| Wellendichtung | a : single primary | ||
| pump rotation (shaft end view) | r : right hand (clockwise) | ||
| paint | a : painted blue | ||
| design code | 32 : thirty-second |
| Produkt | vmq2 : vmq vane pump double series | ||
| frame size (rear section) | 25 : 10-80 cm3/r [.62-4.88 in3/r] | ||
| displacement (front section) | 125 : 125.0 cm3/r [7.63 in3/r] 35 frame size | ||
| front mounting flange type | b : sae j744 127-2 (sae c) 2 bolt 127.00 [5.000] dia. x 12.4 [.49] pilot 17.6 [.69] dia. slots on 181.0 [7.13] dia. bolt circle | ||
| input shaft type | 05 : keyed shaft per sae j744 for 25, 35 or 45 frame | ||
| inlet port type | b : 4-bolt flange per sae j518 with metric threads | ||
| rear outlet port type | b : 4-bolt flange per sae j518 with metric threads | ||
| rear outlet port pos. (cover end view) | c : rear outlet port 45 deg. clockwise from inlet port - (not available with 2525) | ||
| Seal Type | n : buna n | ||
| special features | 00 : none | ||
| customer identification | 0 : none |
