| Height with seat washer | T1 | 79 | mm |
| Minimum chamfer dimension | rmin | 0,60 | mm |
| Distance of the center point | A | 34,50 | mm |
| Height shaft washer | B | 15 | mm |
| Maximum filled radius | ra max | 0,60 | mm |
| Maximum diameter shaft shoulder | da max | 60 | mm |
| Maximum diameter of housing shoulder | Da max | 85 | mm |
| Reference speed | nϑr | 5,200 | |
| Fatigue load limit, axial | Cua | 10,000 | |
| Basic dynamic load rating, axial | Ca | 105,000 | |
| Outer diameter housing washer | D | 115 | mm |
| Limiting speed | nG | 3,050 | |
| Basic static load rating, axial | C0a | 220,000 | |
| Höhe | T | 70,60 | mm |
| Inner diameter shaft washer | d | 50 | mm |
