| activation | electrically | ||
| working pressure max | 16 bar | ||
| voltage tolerance ac 50 hz | -20% / +10% | ||
| pilot valve width | 30 mm | ||
| switch-on power ac 50 hz | 10 va | ||
| max. ambient temperature | 50 °c | ||
| protection class with connection | ip65 | ||
| Gewicht | 0.162 kg |
| working pressure min. | 0 bar | ||
| operational voltage ac at 50 hz | 230 v | ||
| Standards | cnomo / nfe 49-003-1 | ||
| holding power ac 50 hz | 8 va | ||
| min. ambient temperature | -10 °c | ||
| Medium | compressed air | ||
| Einschaltdauer | 100 % |
