| Bore diameter | d | 55 | mm |
| Höhe | H | 50,50 | mm |
| Outside diameter shaft washer | d1 | ≈120 | |
| Inner diameter sphered seat washer | D2 | 88 | mm |
| Height sphered housing washer | C | 15,50 | mm |
| Centre height housing washer sphere | s | 28 | mm |
| Außen-Ø | d2 | 120 | mm |
| Height bearing including seat washer | H1 | 55 | mm |
| Inner diameter housing washer | D1 | ≈57 | |
| Outside diameter sphered housing washer | D3 | 125 | mm |
| Radius sphered housing washer | R | 90 | mm |
| Chamfer dimension washer | r1,2 | min.1.5 |
