| Inner diameter shaft washer | d | 260 | mm |
| Höhe | T | 45 | mm |
| Basic static load rating, axial | C0a | 1,070,000 | |
| Limiting speed | nG | 1,560 |
| Outer diameter housing washer | D | 320 | mm |
| Basic dynamic load rating, axial | Ca | 245,000 | |
| Fatigue load limit, axial | Cua | 29,000 | |
| Reference speed | nϑr | 1,390 |
| Minimum diameter shaft shoulder | da min | 296 | mm |
| Maximum filled radius | ra max | 1,50 | mm |
| Maximum diameter of housing shoulder | Da max | 284 | mm |
| Minimum chamfer dimension | rmin | 1,50 | mm |
| Outer diameter shaft washer | d1 | 317 | mm |
