FESTO 4821481 Stiftbaugruppe

Name: 4821481 FESTO
Brand: FESTO
SKU: 832569-de-eur
Price: 13.05 EUR
Availability: SoldOut

EXCM-30-

13,05 € ~~22,07 €~~ -40%

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

Baugröße	30

Einbaulage	optional

Baugröße		30
Operating mode of drive unit		Micro step, 2000 steps/revolution
Position sensor		Encoder
Protective function		I²t monitoring Temperature monitoring Current monitoring Voltage failure detection Following error monitoring Software end-position detection
Type of interpolation		Linear interpolation
Position mode		Record selection mode Position directly transferred
Anzeige		7-segment LED
Max. Geschwindigkeit		0,5 m/s ... 1 m/s
Brake resistance		15 Ohm
Einschaltdauer		100%
Nominal voltage for logic power supply DC		24 V
Parameterisation interface		Ethernet
Ethernet, supported protocols		TCP/IP
CE-Zeichen (siehe Konformitätserklärung)		To EU EMC Directive
Relative Luftfeuchtigkeit		0 - 90% Non-condensing
Schutzart		IP20
Motor holding torque		0,5 Nm
Max. Kraft Fz		1.345 N
Max. Moment My		10,9 Nm
Max. process force in Z direction		100 N
Guide value nominal load, horizontal		3 kg
Feed constant		38 mm/U
Number of digital logic inputs		8
Process interfacing		I/O coupling For 31 sets
Working range of logic input		24 V
Switching logic for inputs		NPN (negative switching) PNP (positive switching)
Communication interface, logic		CAN DS 301 I/O 31pos Ethernet - TCP/IP
Werkstoff-Hinweis		Contains paint-wetting impairment substances RoHS-compliant

Controller operating mode		PWM MOSFET power output stage Cascade controller with P position controller PI speed controller PI current regulator
Einbaulage		optional
Mains filter		Integrated
Konstruktiver Aufbau		Planar surface gantry
Type of motor		Stepper motor
Sicherheitsfunktion		Safe torque off (STO)
Max. acceleration		10 m/s² ... 20 m/s²
Wiederholgenauigkeit		±0.05 mm
Features of digital logic outputs		Not galvanically isolated
Max. current digital logic outputs		100 mA
Nominal voltage load voltage DC		24 V ... 48 V
Position control		yes
Permissible range for logic voltage		± 15 %
Lagertemperatur		-10 °C ... 60 °C
Schalldruckpegel		52 dB(A)
Umgebungstemperatur		10 °C ... 45 °C
Max. drive torque		0,2 Nm
Max. Moment Mx		5,5 Nm
Max. Moment Mz		5,5 Nm
Nenn-Anziehdrehmoment		0,04 Nm
Guide value nominal load, vertical		2 kg
Number of digital logic outputs 24 V DC		5
Communication profile		FHPP
Specification logic input		Based on IEC 61131-2
Features of logic input		Galvanically connected to logic potential
Switching logic for outputs		NPN (negative switching) PNP (positive switching)
Befestigungsart		Profile mounting
