| motors | hhd463321bc00000000000b | ||
| Schluckvolumen | 46 : 75,33 cm3/r [4.594 in3/r] at 18 deg. swashplate angle | ||
| Design type | 3 : fixed clearance - (models 33-64) | ||
| main ports | b : [1.00] sae 4-bolt split flange port, high pressure series (code 62) | ||
| charge pressure relief valve | 0 : no relief valve | ||
| high pressure relief valve - port a | 0 : none | ||
| high pressure relief valve - port b | 0 : none | ||
| speed sensor | 0 : no speed sensor | ||
| paint and packaging | 0 : painted primer blue | ||
| design code | b : b |
| Product identification | hhd : heavy duty hydrostatic fixed displacement motor | ||
| Typ | 3 : fixed displacement motor | ||
| output shaft | 21 : 21 tooth 16/32 pitch spline (models 33-64) | ||
| end cover and composite valve block assy | c : no composite valve block - with cover plate | ||
| charge pressure relief valve setting | 0 : standard | ||
| high pressure rel valve setting - port a | 0 : none | ||
| high pressure rel valve setting - port b | 0 : none | ||
| special features | 00 : no special features | ||
| identification on unit | 0 : standard |
