| minimum bend radius | 55 mm | ||
| hose i.d. (size) | -5 | ||
| Baugröße | -5 | ||
| division | polymer hose division europe | ||
| Anwendung | demanding medium pressure hydraulic applications in all markets | ||
| Produktfamilie | hydraulic hose, specialty hose | ||
| maximum operating pressure | 5800 psi, 40 mpa, 400 bar | ||
| hose outside diameter | 15, 0.590 inch | ||
| cover color | black | ||
| Maximale Betriebstemperatur | 100 °c (water: 85 , air: 70), 212 °f (water: 185, air: 158) | ||
| specifications met | en 857 2sc, iso 11237 type 2sc, en 857 2sc - iso 11237 type 2sc | ||
| cover material | highly abrasion resistance msha approved | ||
| hose reinforcement material | 2 high tensile steel wire braids |
| hose cover type | tough cover | ||
| media | petroleum & water-glycol based fluids, lubricating oils, fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, lubricants | ||
| Brand | parker | ||
| industry | general industrial, off-road machinery | ||
| technology | fluid & gas handling | ||
| product style | elite no-skive compact tough cover | ||
| hose inside diameter | 7.9 mm, 5/16 inch | ||
| design factor | 4:1 | ||
| compatible fitting | 46 series, 48 series | ||
| Minimale Betriebstemperatur | -40 °c | ||
| materials of construction | rubber | ||
| hose inner tube material | nitrile nbr | ||
| Gewicht | 0.35 kg/m, 0.23 lb/ft |
