PARKER 4222 15 21 20

Name: 4222 15 21 20 PARKER
Brand: PARKER
SKU: 805901-de-eur
Price: 167.97 EUR
Availability: InStock

167,97 €

verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Technische Daten

max. Druck	10 bar, 1 mpa, 145.04 psi
Max. Volumenstrom	2.44 dm3/sec

Dichtung	fkm
Gewicht	1,05Kg

Betriebsdruck		vacuum to 10 bar
region of origin		italy
Gewicht		1.050 kg, 2.310 lb
seal material		fkm
specifications met		di: 97/23/ec (module ped a - diameters greater than 25 mm), rohs, reachdi: 2006/42/ec (machinery directive), di: 2002/95/ec (rohs), rg: 1907/2006 (reach), di: 94/9/ec (atex) - for pneumatic operation versions
Mounting type		in-line
Maximale Betriebstemperatur		135 °c, 275 °f
for fluid type		air, oil, water
orifice size		1/2 inch
connection size		g1/2
Anschlussgröße		g1/8
Anzahl Anschlüsse		2
maximum flow rate		2.44 dm3/sec
maximum pilot pressure		8 bar
operation type		electro-pneumatic drive
product series		axial valves
valve type		axial
technology		fluid & gas handling, process control, pneumatics
industry		industrial manufacturing equipment
Brand		legris
connection 1 thread size (metric)		g1/2

vacuum pressure rating		740 mm-hg
quantity per box		1
o-ring material		fkm
body material		nickel plated brass
actuation type		air pilot
Minimale Betriebstemperatur		-20 °c, -4 °f
media		air, oil, water
configuration		2/2
Leitungsanschlüsse		g1/8
Anschlussart		bspp
port type		thread
flow rate		2.44 dm3/sec
minimum pilot pressure		3 bar
maximum operating pressure		10 bar, 1 mpa, 145.04 psi
Funktion		2-way, double acting
product style		female axial valve
Produktfamilie		axial valves
Anwendung		pneumatic, process control, safety, fluid control, plastic injection molding, rubber industry, textile, printing, packaging, robotics
division		low pressure connectors europe division
shape		in-line
