| Part # | 4219G 1/4" | ||
| Continuous Operating Temperature Range | -40°F to +257°F | ||
| Hose Inside Diameter (in) | 0,25 | ||
| Hose Outside Diameter (in) | 0,50 | ||
| Inside Diameter (in) | 1/4 | ||
| Temperature Range | -40/125 | ||
| Max. Working Pressure (Bar) | 3 | ||
| Outside Diameter (mm) | 12,70 | ||
| Color | BLACK | ||
| Construction: Cover | Type C2 (Modified Nitrile). Black. Fuel, oil, ozone and high temperature resistant. | ||
| Construction: Reinforcement | YS | ||
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. | ||
| Meets These Agency Specifications | SAE - Society of Automotive Engineers | ||
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. | ||
| Weight (lbs.) | 0,10 |
| Product # | 4219-00103 | ||
| Minimum Bend Radius (mm) | 80 | ||
| Hose Inside Diameter (mm) | 6,40 | ||
| Hose Outside Diameter (mm) | 12,70 | ||
| Inside Diameter (mm) | 6 | ||
| Max. Working Pressure | 50 | ||
| Outside Diameter (in) | 0,50 | ||
| Markets/Applications | Fuel | ||
| Cover | NBR/PVC | ||
| Construction: Design Factor | 5 | ||
| Construction: Tube | NBR | ||
| Standard Industry Specification | SAE 30R6, SAE 30R7 | ||
| Standards: Tube | ARPM (Class A) High oil-resistance. | ||
| Caution | Not recommended for fuel injection systems. | ||
| UPC | 072053132854 |
