| Baugröße | -4 | ||
| Anwendung | petroleum based hydraulic fluids & lubricating oils | ||
| specifications met | iso 18752 | ||
| minimum bend radius | 2 inch, 1/2 minimum iso 18752 bend radius mm | ||
| hose reinforcement material | 1 braid steel wire | ||
| maximum operating pressure | 3000 psi, 21 mpa | ||
| hose outside diameter | 0.53 inch, 13.4 mm | ||
| hose inside diameter | 1/4 inch, 6.3 mm | ||
| disclaimer | the user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met. the user must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalog and in any other materials provided from parker or its subsidiaries or authorized distributors. refer to fluid connectors safety guide. | ||
| hose cover type | supertough |
| cover color | black | ||
| compatible fitting | 43 series | ||
| Maximale Betriebstemperatur | 257 °f, 125 °c | ||
| cover material | synthetic rubber super abrasion resistant | ||
| hose inner tube material | synthetic rubber | ||
| nominal hose inside diameter | 6 | ||
| media | hydraulic fluids, lubricants | ||
| Minimale Betriebstemperatur | -40 °c, -40 °f | ||
| Gewicht | 0.24 kg/m, 0.16 lb/ft | ||
| hose i.d. (size) | -4 |
