| Quantity per Box | 5 | ||
| Application | Robotics, Automotive Process, Pneumatics, Semi-Conductors, Textile, Packaging | ||
| Specifications Met | ISO 14743, DI: 97/23/EC (PED), DI : 2002/95/EC (RoHS), 2011/65/EC, DI : 1907/2006 (REACH) | ||
| Connection 1 Thread Style | na | ||
| Shape | Connector for 3 tubes in line | ||
| Connection 1 Thread Size (metric) | na | ||
| Number of Outlets | na | ||
| Body Material | TECHNICAL POLYMER | ||
| Gripping Ring Material | STAINLESS STEEL | ||
| Vacuum Pressure Rating | 755 mm-Hg |
| Gewicht | 0,028 kg | ||
| Media | Compressed Air, Other fluids: please consult us | ||
| Produktfamilie | Modular Plug-In Connectors | ||
| Connection 2 Thread Style | na | ||
| Connection 2 Thread Size (metric) | na | ||
| Connection 3 Tube O.D. (inch) | na | ||
| Connection 3 Tube O.D. (mm) | 6 | ||
| O-Ring Material | NBR | ||
| Maximum Operating Pressure | 20 barg |
