| Minimum chamfer dimension | rmin | 2 | mm |
| Shoulder diameter inner ring | d1 | 77,30 | mm |
| Contact angle | α | 45 | ° |
| Shoulder diameter outer ring | D1 | 96,90 | mm |
| Distance between the apexes of the pressure cones | a | 104 | mm |
| Bore diameter | d | 50 | mm |
| Breite | B | 44,40 | mm |
| Basic static load rating, radial | C0r | 84,000 | |
| Limiting speed | nG | 8,700 |
| Außen-Ø | D | 110 | mm |
| Basic dynamic load rating, radial | Cr | 90,000 | |
| Fatigue load limit, radial | Cur | 5,300 | |
| Reference speed | nϑr | 5,300 |
| Minimum diameter shaft shoulder | da min | 61 | mm |
| Maximum fillet radius | ra max | 2 | mm |
| Maximum diameter of housing shoulder | Da max | 99 | mm |
