| product style | banjo | ||
| connection 2 size | g 1/8 | ||
| configuration | tube to port | ||
| Gewicht | 0,018 kg | ||
| gripping ring material | stainless steel | ||
| media | compressed air, other fluids: please consult us | ||
| Minimale Betriebstemperatur | -20 °c | ||
| specifications met | iso 14743, di: 97/23/ec (ped), di : 2002/95/ec (rohs), 2011/65/ec, di : 1907/2006 (reach) | ||
| Anwendung | robotics, automotive process, pneumatics, semi-conductors, textile, packaging |
| shape | elbow 90° | ||
| connection 2 type | male bspp | ||
| connection 1 size | 4 mm (o.d) 5/32 inch | ||
| vacuum pressure rating | 755 mm-hg | ||
| Maximale Betriebstemperatur | 80 °c | ||
| quantity per box | 10 | ||
| maximum operating pressure | 20 barg | ||
| o-ring material | nbr |
