| hose cover type | standard | ||
| Maximale Betriebstemperatur | 212 (water: 185, air: 158) °f, 100 (water: 85, air: 70) °c | ||
| media | air, water, fuels (check fuel type with our catalogue chart)., coolants i.e. glycol, lubricants, mineral hydraulic oil, lubricants i.e. oils | ||
| industry | off-road machinery, industrial manufacturing equipment | ||
| technology | fluid & gas handling | ||
| product style | no-skive | ||
| hose inside diameter | 12.7 mm, 1/2 inch | ||
| minimum bend radius | 180 mm, 7.087 inch | ||
| cover color | black | ||
| Minimale Betriebstemperatur | -40 °c | ||
| materials of construction | rubber | ||
| hose inner tube material | nitrile nbr | ||
| Gewicht | 0.67 kg/m, 0.45 lb/ft |
| hose i.d. (size) | -8 | ||
| Brand | parker | ||
| division | polymer hose division europe | ||
| Anwendung | general medium pressure hydraulic applications | ||
| Produktfamilie | hydraulic hose | ||
| maximum operating pressure | 4000 psi, 27.5 mpa, 275 bar | ||
| hose outside diameter | 22.2 mm, 0.874 inch | ||
| design factor | 4:1 | ||
| compatible fitting | 48 series | ||
| specifications met | en 853 2sn, iso 1436 type 2, sae 100r2at, sae 100 r2at | ||
| cover material | synthetic rubber | ||
| hose reinforcement material | two high - tensile steel wire braids |
