| pumps | gr pump (l2-dist) | ||
| relief valve | a : plain | ||
| Schluckvolumen | 04 : 38.2 cm3/r [2.33 in3/r] | ||
| port sizes & location - backplate | 01 : plain, suction port 1.625-12 un-2b sae o-ring port; pressure port 1.0625-12 un-2b sae o-ring port - side ports | ||
| relief valve full flow setting | 00 : no relief valve setting | ||
| test data | 0 : generic | ||
| paint | 0a : primer per spec 209-13a | ||
| design code | a : a |
| code title | abf : l2 gear pump (single unit) | ||
| input rotation | r : right-hand rotation (cw) | ||
| input shaft | aa : 13 tooth 16/32 spline, shaft ext 41.1 [1.62] | ||
| priority flow divider setting | 00 : no flow setting | ||
| auxiliary mounting feature (rear) | 0 : no auxiliary mounting features | ||
| special features | 00 : no special features | ||
| identification | 0 : standard |
