| ra max - Max shaft & housing fillet radius | 2,5 mm | ||
| da min - Min shoulder diameter IR | 104 mm | ||
| BSF - Characteristic rolling element frequency | 4,685 Hz | ||
| BPFI - Characteristic inner ring frequency | 8,401 Hz | ||
| Tmax - Max operating temperature | 200 °C | ||
| Nlim - Mechanical Limit Speed | 3500 tr/min | ||
| Y2 - Upper axial load coefficient | 3,07 | ||
| Y0 - Static axial load coefficient | 2,01 | ||
| Cu - Fatigue limit load | 71,4 kN | ||
| C - Dynamic load | 668 kN | ||
| k - Hole diameter | 5 mm | ||
| Number of lubrication holes | 3 | ||
| D1 - Inner diameter outer ring | 165,1 mm |
| Da max - Max shoulder diameter OR | 176 mm | ||
| da max - Max shoulder diameter IR | 0 mm | ||
| FTF - Characteristic cage frequency | 0,4 Hz | ||
| BPFO - Characteristic outer ring frequency | 5,599 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nref - Reference thermal speed | 3000 tr/min | ||
| Y1 - Lower axial load coefficient | 2,06 | ||
| e - Coefficient | 0,33 | ||
| C0 - Static load | 652 kN | ||
| Radial clearance class | C3 Special | ||
| b - Groove width | 12 mm | ||
| rs - Min fillet radius | 3 mm | ||
| Brand | SNR |
