| ra max - Max shaft & housing fillet radius | 1,5 mm | ||
| da min - Min shoulder diameter IR | 63 mm | ||
| FTF - Characteristic cage frequency | 0,434 Hz | ||
| BPFO - Characteristic outer ring frequency | 8,252 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nref - Reference thermal speed | 6900 tr/min | ||
| Y1 - Lower axial load coefficient | 2,26 | ||
| e - Coefficient | 0,28 | ||
| C0 - Static load | 9,9 kN | ||
| Radial clearance class | CN | ||
| D1 - Inner diameter outer ring | 85,2 mm |
| Da max - Max shoulder diameter OR | 92 mm | ||
| BSF - Characteristic rolling element frequency | 7,352 Hz | ||
| BPFI - Characteristic inner ring frequency | 10,748 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Mechanical Limit Speed | 8400 tr/min | ||
| Y2 - Upper axial load coefficient | 3,50 | ||
| Y0 - Static axial load coefficient | 2,37 | ||
| Cu - Fatigue limit load | 0,45 kN | ||
| C - Dynamic load | 26,3 kN | ||
| rs - Min fillet radius | 1,5 mm | ||
| Brand | SNR |
