| adjusting knob | plated steel | ||
| Einstellung | t-bar | ||
| bonnet | zinc alloy | ||
| elastomers | synthetic rubber | ||
| flow flow dm3secbar | 60 dm3/(s.bar) dm3/sec | ||
| gauge port | g1/8 | ||
| maximum inlet pressure pressure bar | 8 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 3 ... 116 psi | ||
| Anschlussgröße | g1/2 | ||
| range | 20ag |
| adjusting screw | steel | ||
| body | zinc alloy | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 60 dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 116 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.2 ... 8 bar | ||
| product style | special | ||
| relievingnonrelieving | relieving |
