| min. ambient temperature | -40 °c | ||
| temporary ambient temperature (<30 s) min. | -40 °c | ||
| compressed air connection | g 1/4 | ||
| Haltekraft | 120 n | ||
| Volumen | 195 cm³ | ||
| abrasion value according to din 535 16 | 10-12 mm³ | ||
| connection thread type | external thread | ||
| Material connector | aluminum | ||
| delivery unit | 1 piece |
| max. ambient temperature | 80 °c | ||
| temporary ambient temperature (<30 s) max. | 100 °c | ||
| external diameter | 80.2 mm | ||
| separation force | 250 n | ||
| max. curving on object rmin | 60 mm | ||
| hardness according to standard | 72 ± 5 shore a | ||
| low-wear | low-wear | ||
| suction unit material | polyurethane | ||
| Gewicht | 0.145 kg |
