| adjusting knob | acetal resin | ||
| bonnet | zinc alloy | ||
| elastomers | synthetic rubber | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 58 psig | ||
| Medium | compressed air | ||
| operating temperature f temperature fahrenheit min to max range | 32 ... 158 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 1 ... 60 psi | ||
| height length millimetre | 54 mm | ||
| width length millimetre | 54 mm | ||
| Anschlussgröße | g1/4 | ||
| range | 11-818 |
| body | zinc alloy | ||
| data performance shelf life | 3 years | ||
| eu country of origin | czechia | ||
| gauge port | r1/4 | ||
| maximum inlet pressure pressure bar | 4 bar | ||
| mil spec | unavailable | ||
| operating temperature temperature celsius min to max range | 0 ... 70 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.07 ... 4 bar | ||
| length length millimetre | 127 mm | ||
| port connections | g1/4 | ||
| product style | ported | ||
| relievingnonrelieving | relieving |
