| air pilot ports | rc1/4 | ||
| bonnet | aluminium alloy | ||
| elastomers | nitrile rubber | ||
| gauge | no gauge | ||
| inner parts | brass | ||
| maximum inlet pressure pressure bar | 20 bar | ||
| mil spec | available on request | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| length length millimetre | 106 mm | ||
| range | 11-808 |
| body | zinc | ||
| data performance shelf life | 10 years | ||
| eu country of origin | mexico | ||
| gauge port | rc1/8 | ||
| maximum inlet pressure imperial pressure psi | 290 psig | ||
| Medium | compressed air | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 176 °f | ||
| diameter length millimetre | 125 mm | ||
| Anschlussgröße | g1 | ||
| relievingnonrelieving | relieving |
