| motors | mh0097aa01ab0000000000j0 j | ||
| Baureihe | h0 : h series motor | ||
| Mounting type | aa : 2 bolt std - 82.50 [3.248] dia. x 3.05 [.120] pilot, 13.59 [.535] dia. mounting holes on 106.35 [4.187] dia. b.c. | ||
| port type | ab : .500-14 nptf dryseal pipe thread ports | ||
| gerotor options | 0 : none | ||
| seal options | 00 : standard seals | ||
| valve options | 00 : none | ||
| special assembly instructions | 0 : none | ||
| customer id./nameplate options | 00 : none specified |
| Produkt | m : motor | ||
| Schluckvolumen | 097 : 159 cm3/r [9.7 in3/r] | ||
| output shaft | 01 : 25.4 [1.00] dia. straight, woodruff key, .250-20 unc-2b hole in shaft end | ||
| case flow options | 00 : none specified | ||
| shaft options | 0 : none | ||
| speed sensor options | 00 : none | ||
| special features (hardware) | 00 : none specified | ||
| paint/packaging options | aj : painted low gloss black, 2 mils min thick | ||
| design code | j : nine (9) |
