AVENTICS 0821305165

Name: 0821305165 AVENTICS
Brand: AVENTICS
SKU: 754072-de-eur
Price: 265.82 EUR
Availability: InStock

ECV-PC-15-NN-A-S-NN-G018-G018-S001

265,82 € ~~297,82 €~~ -10%

verfügbar mit 7 bis 15 Tagen Lieferzeit nach United States

Technische Daten

max. Druck	6 bar
Dichtung	acrylonitrile butadiene rubber

Gewicht	110g

activation		electrically
nozzle Ø		1.5 mm
working pressure max		6 bar
max. ambient temperature		50 °c
max. medium temperature		50 °c
oil content of compressed air min.		0 mg/m³
max. particle size		5 µm
vacuum connection+		g 1/8
air consumption at p.opt.		116 l/min
Gewicht		0.11 kg
seal material		acrylonitrile butadiene rubber
silencer material		polyethylene

with silencer		with silencer
working pressure min.		3 bar
min. ambient temperature		0 °c
min. medium temperature		0 °c
Medium		compressed air
oil content of compressed air max.		1 mg/m³
compressed air connection		g 1/8
max. suction capacity		63 l/min
sound pressure level intake effect		73 db
Gehäusematerial		polyamide fiber-glass reinforced
nozzle material		brass
