| Typ | can be assembled into blocks | ||
| mounting orientation | any | ||
| Ausführung | distributor 4x | ||
| working pressure max | 16 bar | ||
| max. ambient temperature | 60 °c | ||
| nominal flow qn 1 to 2 | 700 l/min | ||
| nominal flow qn 1 to 4 | 450 l/min | ||
| nominal flow 1 ▶ 6 | 450 l/min | ||
| Gehäusematerial | die cast zinc | ||
| seal material | acrylonitrile butadiene rubber |
| parts | distributor | ||
| port | g 1/4 | ||
| working pressure min. | 0.1 bar | ||
| min. ambient temperature | -10 °c | ||
| Medium | compressed air, neutral gases | ||
| nominal flow 1 ▶ 3 | 675 l/min | ||
| nominal flow 1 ▶ 5 | 675 l/min | ||
| Gewicht | 0.33 kg | ||
| material front plate | acrylonitrile butadiene styrene |
